SLC-MP Series

SKAN Bag & Filters

SLC-MP Series

  • Flows up to 3.0 L/s
  • Durable reinforced polypropylene housings, larger diameter (4.5”)
  • Pressure relief/bleed valve
  • Supplied with mounting screws, bracket & spanner.
  • Watermark® Certification
  • Max operating pressure: 830kPa
  • Max operating temperature: 45°C
  • Min operating temperature: 4°C

Models & Specs

CODE DESCRIPTION FLOW RATE M3/HOUR (L/S)
S05300501 SLC-MP-1025 10″ Poly Cartridge Housing, 25mm 5.4 (1.5)
S05300502 SLC-MP-2025 20″ Poly Cartridge Housing, 25mm 7.2 (2.0)
S05300503 SLC-MP-2040 20″ Poly Cartridge Housing, 40mm 10.8 (3.0)

S15200501 Pleated Sediment Cartridge 10″, Large Diameter, 1um
S15200502 Pleated Sediment Cartridge 10″, Large Diameter, 5um
S15200503 Pleated Sediment Cartridge 10″, Large Diameter, 20um
S15200504 Pleated Sediment Cartridge 10″, Large Diameter, 50um
S15200505 Pleated Sediment Cartridge 10″, Large Diameter, 100um
S15201001 Pleated Sediment Cartridge 20″, Large Diameter, 1um
S15201002 Pleated Sediment Cartridge 20″, Large Diameter, 5um
S15201003 Pleated Sediment Cartridge 20″, Large Diameter, 20um
S15201004 Pleated Sediment Cartridge 20″, Large Diameter, 50um
S15201005 Pleated Sediment Cartridge 20″, Large Diameter, 100um

S15300501 Pleated Carbon Cartridge 10″, Large Diameter, 10um
S15301001 Pleated Carbon Cartridge 20″, Large Diameter, 10um

S15150501 Polyspun Sediment Cartridge 10″, Large Diameter, 1um
S15150502 Polyspun Sediment Cartridge 10″, Large Diameter, 5um
S15150503 Polyspun Sediment Cartridge 10″, Large Diameter, 10um
S15150504 Polyspun Sediment Cartridge 10″, Large Diameter, 20um
S15150505 Polyspun Sediment Cartridge 10″, Large Diameter, 50um
S15151001 Polyspun Sediment Cartridge 20″, Large Diameter, 1um
S15151002 Polyspun Sediment Cartridge 20″, Large Diameter, 5um
S15151003 Polyspun Sediment Cartridge 20″, Large Diameter, 10um
S15151004 Polyspun Sediment Cartridge 20″, Large Diameter, 20um
S15151005 Polyspun Sediment Cartridge 20″, Large Diameter, 50um

S15403001 Carbon Block Cartridge 10″, Large Diameter, 10um
S15403002 Carbon Block Cartridge 20″, Large Diameter, 10um

Spare Parts

Model CODE DESCRIPTION
SLC-MP Series S05300508 Housing Spanner to suit 10″ & 20″ Housings
S05300509 Heavy Duty Wall Mount Bracket – Single
S05300510 Heavy Duty Wall Mount Bracket – Twin
S05300511 Filter Housing O-ring to suit SCL-MP/DEFENDER Series
S05900003 Pressure Gauge, 0-1,000kPa, Liquid filled, Bottom Mount

Accessory

Code: S05900001
Model: SLB-PD Pressure Differential Alarm System
Description:
– Monitors inlet and outlet pressure of filter system
– Audible and visual alarm when pressure differential is reached
– BMS output for remote alarm monitoring
– SUpplied with 1/4″ tube and isolation valve
