Carbon Media Filters

MediaPRO

Carbon Media Filters

Single & Duplex Activated Carbon Filters

  • Reduces Chlorine, chlorine taste and odour. Decreases organic based colour, taste, odour, pesticides and chemicals.
  • Media filtration using a bed of carbon, crushed glass, anthracite, crushed granite or other material.
  • Fully automatic media filtration
  • Used to filter water for various applications e.g. drinking, swimming pools, aquaculture, irrigation, stormwater management, oil and gas operations.

Single Activated Carbon Filter Specifications

Code Service Flow (lpm) Peak Service Flow (lpm) Backwash Flow (lpm) Min Operating Pressure Max Operating Pressure Inlet/Outlet Connection Size Drain Connection Size
S-09-CF 8 16 16 240kPa 700kPa 25mm BSPM 19mm Hose Barb
S-10-CF 10 20 20 240kPa 700kPa 25mm BSPM 19mm Hose Barb
S-12-CF 15 30 28 240kPa 700kPa 25mm BSPM 19mm Hose Barb
S-13-CF 18 36 34 240kPa 700kPa 25mm BSPM 19mm Hose Barb
S-14-CF 20 40 41 240kPa 700kPa 32mm BSPM 25mm Hose Barb
S-16-CF 26 53 56 240kPa 700kPa 32mm BSPM 25mm Hose Barb
S-18-CF 33 67 66 240kPa 700kPa 40mm BSPF 40mm BSPF
S-21-CF 45 91 92 240kPa 700kPa 40mm BSPF 40mm BSPF
S-24-CF 59 119 119 240kPa 700kPa 50mm BSPF 50mm BSPF
S-30-CF 93 187 186 240kPa 700kPa 50mm BSPF 50mm BSPF
S-36-CF 134 269 269 240kPa 700kPa 50mm BSPF 50mm BSPF
S-42-CF 183 366 365 240kPa 700kPa 80mm BSPF 80mm BSPF
S-48-CF 239 478 479 240kPa 700kPa 80mm BSPF 80mm BSPF
S-63-CF 411 822 821 240kPa 700kPa 80mm BSPF 80mm BSPF

Duplex Activated Carbon Filter Specifications

Code Service Flow (lpm) Peak Service Flow (lpm) Backwash Flow (lpm) Min Operating Pressure Max Operating Pressure Inlet/Outlet Connection Size Drain Connection Size
D-09-CF 16 32 16 240kPa 700kPa 25mm BSPM 19mm Hose Barb
D-10-CF 20 40 20 240kPa 700kPa 25mm BSPM 19mm Hose Barb
D-12-CF 30 60 28 240kPa 700kPa 25mm BSPM 19mm Hose Barb
D-13-CF 36 72 34 240kPa 700kPa 25mm BSPM 19mm Hose Barb
D-14-CF 40 80 41 240kPa 700kPa 32mm BSPM 25mm Hose Barb
D-16-CF 53 106 56 240kPa 700kPa 32mm BSPM 25mm Hose Barb
D-18-CF 67 134 66 240kPa 700kPa 40mm BSPF 40mm BSPF
D-21-CF 91 182 92 240kPa 700kPa 40mm BSPF 40mm BSPF
D-24-CF 119 238 119 240kPa 700kPa 50mm BSPF 50mm BSPF
D-30-CF 187 376 186 240kPa 700kPa 50mm BSPF 50mm BSPF
D-36-CF 269 538 269 240kPa 700kPa 50mm BSPF 50mm BSPF
D-42-CF 366 732 365 240kPa 700kPa 80mm BSPF 80mm BSPF
D-48-CF 478 956 479 240kPa 700kPa 80mm BSPF 80mm BSPF
D-63-CF 822 1644 821 240kPa 700kPa 80mm BSPF 80mm BSPF
