JPF ATP Series

Judo

JPF ATP Series

Pressure Differential Controlled Backwash Filter

  • Flows up to 55.5 L/s
  • Automatic backwash via differential pressure and timer control
  • Extremely efficient screen cleaning ratio of 1:1 using point rotation principle
  • Standard 100 micron stainless steel screen (Silver coated to inhibit bacterial growth)
  • No interruption to water flow during screen cleaning
  • Can be mounted in vertical or horizontal pipe runs
  • Clear viewing glass enables full view of screen and backwash operation
  • BMS connection for operation, fault, and backwash status available
  • Minimum operating pressure: 200kPa
  • Pressure class (25mm-DN65): PN16
  • Pressure class (DN80-DN200): PN10

Models & Specs

CODE Model FLOW RATE M3/HOUR (L/S)
J8020357 JPF ATP 25mm (1″) 7.6 (2.1)
J8020358 JPF ATP 32mm (1 1/4″) 8.5 (2.3)
J8020359 JPF ATP 40mm (1 1/2″) 18.0 (5.0)
J8020360 JPF ATP 50mm (2″) 22.0 (6.1)
J8025008 JPF ATP DN65 28.0 (7.7)
J8025100 JPF ATP DN65 w/ BMS 28.0 (7.7)
J8025018 JPF ATP DN80 w/ BMS 65.0 (18.0)
J8025019 JPF ATP DN100 w/ BMS 78.0 (21.6)
J8020035 JPF ATP DN125 w/ BMS 100.0 (27.7)
J8020036 JPF ATP DN150 w/ BMS 150.0 (41.6)
J8020037 JPF ATP DN200 w/ BMS 200.0 (55.5)

* UPGRADES FOR JPF ATP SERIES:

J0085001 JUDO BMS upgrade to suit JPF series
J0086030 JUDO Screen upgrade to JPF (30 micron)
J0086050 JUDO Screen upgrade to JPF (50 micron)*
J0086320 JUDO Screen upgrade to JPF (320 micron)
J0086500 JUDO Screen upgrade to JPF (500 micron)

* Only available with 40mm-DN200 systems.

Spare Parts

Model Code Description
JPF 20-32mm Series J2010335 Spare Parts Kit to suit JPF 20-32mm
J2020728 30 Micron Screen & Suction Arm Assembly suits JPF 20-32mm (inc. seal kit)
J2021359 100 Micron Screen & Suction Arm Assembly suits JPF 20-32mm (inc. seal kit)
J2020734 320 Micron Screen & Suction Arm Assembly suits JPF 20-32mm (inc. seal kit)
J2020740 500 Micron Screen & Suction Arm Assembly suits JPF 20-32mm (inc. seal kit)
J2020680 Circuit Board (Standard)
J2020972 Pressure Differential Switch Kit
J2320135 Motor/Gearbox Assembly
JPF 40-65mm Series J2020788 Potential Free Circuit Board Conversion Kit
J2010337 Spare Parts Kit to suit 40-65mm JPF Models
J2020730 30 Micron Screen & Suction Arm Assembly suits JPF 40-50mm (inc. seal kit)
J2020746 50 Micron Screen & Suction Arm Assembly suits JPF 40-50mm (inc. seal kit)
J2021360 100 Micron Screen & Suction Arm Assembly suits JPF 40-50mm (inc. seal kit)
J2020736 320 Micron Screen & Suction Arm Assembly suits JPF 40-50mm (inc. seal kit)
J2020742 500 Micron Screen & Suction Arm Assembly suits JPF 40-50mm (inc. seal kit)
J2020680 Circuit Board (Standard)
J2020972 Pressure Differential Switch Kit
J2320135 Motor/Gearbox Assembly
J2020788 Potential Free Circuit Board Conversion Kit
JPF 80-200mm SERIES & JFXL Series J2010339 Spare Parts Kit to suit 80-200mm JPF Models
J2020732 30 Micron Screen & Suction Arm Assembly to suit JPF 80-200mm (inc. seal kit)
J2020748 50 Micron Screen & Suction Arm Assembly to suit JPF 80-200mm (inc. seal kit)
J2021361 100 Micron Screen & Suction Arm Assembly to suit JPF 80-200mm (inc. seal kit)
J2020738 320 Micron Screen & Suction Arm Assembly to suit JPF 80-200mm (inc. seal kit)
J2020680 Circuit Board (Standard)
J2020972 Pressure Differential Switch Kit
J2320135 Motor/Gearbox Assembly
J2020788 Potential Free Circuit Board Conversion Kit
